X-RAY GENERATOR & IMAGE PERFORMANCE

Voltage:                            160kV, Operation at 150kV

Tube Current:                 0.7 mA

Wire Resolution:            40 AWG Typical,38 AWG Standard

Steel Penetration:          39mm Typical, 37 mm Standard

Cooling:                            Sealed Di-Electric Bath with Forced Air

Duty Cycle:                       100%, No Warm-Up Procedure Required

Beam Direction:               Diagonally Upward

COMPUTER & VIDEO

Platform:                           Windows® 10 OS

Memory:                            8 GB RAM

Storage Capacity:             256 GB SSD

Display Type:                    21.5” Flat Panel Color Monitor

Display Resolution:          1920 x 1080

ENVIRONMENTAL

Operating Temperature:               0ºC to 40ºC / 32ºF to 104ºF

Storage Temperature:                   -20ºC to 60ºC / -4ºF to 140ºF

Humidity:                                         Up to 95% non-condensing

ELECTRICAL

System Power:                  110 VAC +/- 10% 50/60Hz, 15 Amp Max

220 VAC +/- 10% 50/60Hz, 10 Amp Max

Power Conditioner:         Automatic Voltage Regulator (AVR), 600VA

HEALTH & SAFETY

Film Safety:                        Guaranteed up to ISO 1600 (33 DIN)

Compliant with USFDA Center for Devices and Radiation Health Standards for Cabinet X-Ray Systems (21-CFR 1020.40)

Typical radiation leakage is less than 0.1 mR/hr (Leakage less than 0.5 mR/hr permitted by U.S. Federal Standards)
